Lathe guard

· Protect the chuck from getting hurt

· Anti-shattering and splashing

· Safety interlock to monitor the status of the protective cover

· Configure safety control box circuit

· Installation indicator light for easy viewing of alarm status

Meet the general requirements of GB T 8196-2018 mechanical safety protection device fixed and movable protection device design and manufacturing

Product technical description

· Control of access to the hazardous area The design and positioning of the protective cover of the movable lathe should be such that it can prevent the protective cover from closing when there are people left in the hazardous area during normal operation. If this is not feasible, other measures should be taken to prevent the detection of persons in the danger zone. See GB/T 15706-2012, 6.3.3.2.3.

Product patent

· Product patent number: ZL 2014 2 0692706.4

· Safety design considerations

  The design of the lathe protective cover should properly consider the machine's foreseeable full life cycle operation and the predictable machine environment, and poor consideration can lead to dangerous conditions that hinder the operation of the machine, which in turn leads to the artificial discard of the provided protective cover. This exposes the operator to greater risks. The foreseeable aspects of the existing operating protective cover are properly considered at the design stage to ensure that the design and manufacturing of the protective cover itself does not create new dangers.

SR301 safety relay

·  It is a safety relay that can customize three groups of safety product inputs

   Lathe door lock + lathe emergency stop + reset button

·  Support up to 3 groups of safety element input

·  ISO 13849-1 Performance Index PLe

·  Built-in self-diagnosis function to detect faults

·  Optional manual/automatic reset

SM601 programmable safety controller

·  Is a configurable safety control module, used in safety relays,

    Lathe door lock + lathe emergency stop + reset button

·  Support up to 6 groups of safety element input

·  2 safety relay inputs

·  4 semiconductor safety outputs

·  ISO 13849-1 Performance Index PLe

·  Optional manual/automatic reset
